Cooper & Hunter 12,000 BTU Indoor Mini Floor Console, 230V, R410A - Ductless Mini Split Air Conditioner Heat Pump
Cooper & Hunter 12,000 BTU Indoor Mini Floor Console, 230V, R410A - Ductless Mini Split Air Conditioner Heat Pump
Summary
The Mini Floor Console from Cooper&Hunter combines sleek aesthetics with versatile functionality, making it an ideal solution for rooms with low ceilings, attics, or other compact spaces. Available in two capacities—12K and 16K Btu/h—this unit can be installed either floor-standing or mounted low on the wall, providing flexibility for different room layouts.
The Mini Floor Console offers dual airflow outlets with larger dimensions, which significantly improve air volume and provide consistent cooling and heating. This model can be paired with both Regular and Hyper Heat Pump Outdoor Units, delivering efficient performance even in extreme temperatures, down to -13°F for Standard units and -22°F for Hyper units.
For added convenience, this system supports user-friendly remote control operation, making it easy to manage indoor comfort. Whether used in a single-zone or multi-zone configuration, the Mini Floor Console is a perfect blend of design and performance.
Important
All units must be installed by a licensed HVAC professional for the warranty to be valid. Registration is required within 60 days of installation and can be completed online or by phone. The installation kit is necessary for the system to function. Ensure that you have selected the desired installation kit above. This kit comes with the option of Pre-Flared 99% Copper Lines, Data Communication Wires, PVC Drainage Attachment, Wrapping Bands, etc.
What's Included
- Indoor Unit CH-12MMC-230VI (12,000 BTU 230V Indoor Floor Console Air Conditioning Unit)
- Optional, Pre-Flared 99% Copper Installation Kit (16ft, 25ft or 50ft.) MUST BE SELECTED ABOVE.
- Wireless Remote Control
- Installation Manual
- User’s Manual
- Manufacturer Warranty
Compatible Standard Outdoor Units
| Capacity | BTU | SKU |
| Dual (2) Zone: | 18,000 BTU | CH-18MES-230VO |
| Dual/Tri (2 or 3) Zone: | 28,000 BTU | CH-28MES-230VO |
| Dual/Tri/Quad (2, 3 or 4) Zone: | 36,000 BTU | CH-36MES-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 48,000 BTU | CH-48MES-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 55,000 BTU | CH-55MES-230VO |
Compatible Hyper Outdoor Units
| Capacity | BTU | SKU |
| Dual (2) Zone: | 19,000 BTU | CH-HPR19M-230VO |
| Dual/Tri (2 or 3) Zone: | 28,000 BTU | CH-HPR28M-230VO |
| Dual/Tri/Quad (2, 3 or 4) Zone: | 36,000 BTU | CH-HPR36M-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 48,000 BTU | CH-HPR48M-230VO |
| Dual/Tri/Quad/Pent (2, 3, 4 or 5) Zone: | 55,000 BTU | CH-HPR55M-230VO |
Sizing and Compatability:
Combination Chart
The capacity and number of systems can vary for each outdoor unit. Consult the combination chart for potential loading configurations. Ensure the total capacity of all connected indoor units aligns with the minimum and maximum loading range of the selected outdoor unit. It is not mandatory to utilize all circuits on an outdoor unit; some circuits may remain sealed without an attached indoor unit.
Warranty
- 7 year compressor limited warranty
- 5 year parts limited warranty (must be installed by a licensed HVAC technician)
- 1 year remote control
Technical Information
Model Number: CH-12MMC-230VI
| Specification | Value |
| System type |
Single/Multi-zone unit
|
| BTU Rated | 12,000 |
| Power source |
208-230V, 1Ph, 60Hz
|
| Dehumidification value (pnt/day) | 1.2 |
| Voltage range (V) | 187-253 |
| Packing dimensions (WxDxH) |
34.06x11.02x28.31
|
| Controller |
RG10K-exclusive remote&wifi kit
|
| Refrigerant piping Liquid/Gas side (inch) | 1/4" - 1/2" |
| EER2 | 13 |
| SEER2 | 25 |
| Unit Net/Gross weight | 32.85/41.45 |
| Unit dimensions (W*H*D) |
31.26x7.87x24.45
|
| Operation Range - Heating | 32~86 |
| Operation Range - Cooling | 60~90 |
| Minimum circuit ampacity | 3 |
| Max.fuse | 15 |
| Indoor Noise Level H/M/L | 40/37/26 |
| Indoor Air Flow |
441.18/376.47/323.53/264.71
|
| Drainage water pipe diameter | 5/8" |
Certifications
Performance Data/Features
- Louver Memory
- Automatic Operation
- Self-Diagnosis
- Auto Swing
- Goldfin Coating
- Inverter Technology
- Multiple Fan Speeds
- Sleep Mode
- Timer
- Auto-restart Function
- Turbo Mode
- Follow Me Mode
- Remote Control included
- Intelligent Pre-Heating
